VMS-1300 / VMS-1600

Video monitor device

In order to remotely control the weld variable, the operator must be able to see the weld area correctly. The Jetview system provides accurate and enlarged images where remote control is required and can be used for various purposes

Function

Because the camera/lens parts are very small and light, they are fitted to the welding torch for continuous viewing of the weld area. The system is designed to observe pre-weld welds and then show a clear and enlarged image of the weld pool during welding.

    · Each system includes the following components:
  • - Cameras and lenses.
  • - Cameras and lens controls.
  • - High intensity halogen lamp
  • - Color Monitor
  • - Normal Mounting Bracket

JETVIEW video monitoring system

- Camera and lens assembly parts

Camera Type Shutter Speed Outputs Functions Temperature Input Voltage Dimensions
NTSC format, CCD color
PAL format, optional CCD color (option)
1/60 - 1/10,000 s composites and S-video aperture, Focus adjustment 7°~60°C(20°~140°F) 12V DC Diameter : 25.4mm
Length : 89mm
Weight : 0.11kg

- VMS-1121-IT Camera Control Unit

Input Voltage Mounting Dimensions
115/230V, 1 Phase, 50/60Hz vertical or horizontal Height : 254mm
Width : 203mm
Depth : 152mm
Weight : 4.6kg

- LC-IT Operator Lens Adjustment Unit

Switches for Mounting Input Voltage Dimensions
aperture - open/close
Focus - Close/Long Distance
Input Power, Lighting
Torch Cross Slide
Wire Guide Location Tracking
115/230V, 1 phase, 50/60Hz VMS Standard Model - LC - IT
Height : 133mm
Width : 430mm
Depth : 394mm
Weight : 5.4kg
Mounting : Table or 483mm shelf
VMSC Small Model - LCC - IT
Height : 64mm
Width : 127mm
Depth : 178mm
Weight : 0.68kg
Mounting : a dedicated table

- Installation Lamp

Type Power
Halogen 6W

- Video monitor

Type Install Screen Pressure voltage
Color – NTSC / PAL Table (Rack or Panel Selection) 355mm(14”) 115/230V, 1 phase, 50/60Hz

- Standard cable

LC-IT with VMS-1121-IT VMS-1121-IT with camera Pressure with VMS-1121-IT
10m(33ft) 3m(10ft) 1.8m(6ft)
